Seabird Sticker Printer china Portable Sticker Printer manufacturer  Label Printer

1. Lower Shell  2. Upper Shell  3. Keyboard Keys  4. Main Keys  5. Screen  6 Cut Buttons  7. Inner Shell  8. Paper Box

Packing List

Printer

Data line

Label box

Usage guide

2. Portable Sticker Printer parameters:

Print by: Inkless Printing (Heat Sensitive)

Resolution: 203dpi

Interface: Bluetooth BLE/SPP

Knife: Manual

Print width: 12MM

Print speed: Max. 15MM/sec

Screen size: 1.8 inch monochrome backlit liquid crystal

Number of keys: 51 full keyboard

Machine size:

Weight: 230G

Battery: 350mA

Standby time: about 3 months

Duration: Print 5 rolls of paper continuously

Charging interface: TYPE-C 5V

Label size:

Smart carton

Twenty optional patterns (late update, customized on demand)

Label length: 6m

Label width: 15mm

Label specification: 3. Anti-label (waterproof, oil-proof, and scratch-proof)

Operating Methods

1. Label tape installation

Remove rear cover, pull off-hook and remove the battery cover

Exposure of front section of label strap during installation

Turn the label tape with your finger and pull the front section back to the knife-edge position

Cover rear cover

2. Introduction to function keys

Handheld Sticker Printer Key description:

Power key: Short press the power button to turn on and long press the power

button to turn off.

Print key: Print

Direction key: Move

Symbol key: Switch symbol input

Chinese/English key: Switch input method (English, Pinyin, and Stroke)

Numeric keys: 0-9, numeric input, or Pinyin\ Stroke input word selection

Letter keys: A-Z, English input, Pinyin input, Stroke input

Delete key: Delete/Return

Enter key: Confirm/New Line

Space key: Input space, select corresponding candidate words and input

Chinese characters (Pinyin and Stroke input)

Shift key: Click Switch for choosing capital and small letter

Set key: References 1

Template key: Select Template Border

Bluetooth key: Enter Bluetooth mode

The company supply Handheld inkjet printer, which include Handheld Printer with APP and Handheld Printer with USB port. Our products have high quality and competitive prices.
