1W 3KVDC Isolated Single Output DC/DC Converters
Visits: 132
    • Price: $ 2.00 Piece(s) / each
    (0 means negotiable)
    Freight fee: Ordinary delivery: Express: EMS:
    Brand: TOPPOWER
    Specifications: Isolated DC/DC converters
    Type New
    Date: 14-06-2022
    Business type: Retail
    Seller details: See Right Sidebar section
    Quantity: Piece(s)( Stock 10000 Piece(s))

    Tip: Welcome to use TopBuySell Intermediary Guarantee of Payment service to secure transactions between buyers and sellers. Details: topbuysell.com/membership/premium-service.php

    Note: When using other ways of payment but not our Intermediary Guarantee of Payment service, buyers and sellers have full responsibility & liability for any risks and financial loss. In this case, we suggest buyers and sellers contact each other directly for details including authentication to avoid scams.
    Product details



    The TPR-1W series are miniature, isolated 1W DC/DC converters in a SIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise and 3KVDC isolation.

    FEATURES

    RoHS compliant

    3KVDC isolation

    Efficiency up to 80%

    Operating temperature: -40℃ to 105℃

    Power density up to 0.90W/cm3

    UL 94V-0 package material

    Footprint from 1.17cm2

    Industry standard pinout

    Input voltage:3.3V,5V, 12V, 15V, 24V

    Output voltage: 3.3V,5V, 9V,12V, 15V, 24V

    Custom solutions available

    CE certification



    SELECTION GUIDE

    Part Number

    Nominal Input Voltage

    Output Voltage

    Output Current (Max./Min)

    Efficiency

    V

    V

    mA

    %

    TPR0303S-1W

    3.3

    3.3

    303/30.3

    72

    TPR0305S-1W

    3.3

    5

    200/20

    74

    TPR0503S-1W

    5

    3.3

    303/30.3

    72

    TPR0505S-1W

    5

    5

    200/20

    /

    68



    TPR0509S-1W

    5

    9

    111/11.1

    78

    TPR0512S-1W

    5

    12

    84/8.1



    76



    TPR0515S-1W

    5

    15

    68/6.8



    79



    TPR0524S-1W

    5

    24

    42/4.2

    81

    TPR1203S-1W

    12

    3.3

    303/30.3

    74

    TPR1205S-1W

    12

    5

    200/20



    69



    TPR1209S-1W

    12

    9

    111/11.1

    76

    TPR1212S-1W
