BS437 Single Spigot Cast iron drain Pipe with Flexible rubber ring joint
Description of Single Spigot and Socket Cast iron drain/ventilating Pipe
BS437 Single Spigot and Socket Cast iron drain Pipe with Flexible rubber ring joint
BEISAI Cast Iron Pipe conforming to BS437：1978
Material: Grey Cast Iron
Size: DN75-DN225
Internal and external Coating: Black bitumen
|
(mm) |
Pipe body (mm) |
(mm) |
Socket (mm) |
(mm) |
||||
|
Nominal size |
A |
B |
Nominal Wall thickness C |
F |
G |
H |
J |
Length |
|
DN |
Min Internal diameter A |
Max External diameter B |
Min Internal diameter F |
Nominal External diameter G |
Min Thickness H |
Min Depth J |
L |
|
|
75 |
74.00 |
97.00 |
7.40 |
113.00 |
160.00 |
19.00 |
76.00 |
1830+/-5 |
|
100 |
99.00 |
119.00 |
7.50 |
135.00 |
185.00 |
22.00 |
76.00 |
1830+/-5 |
|
150 |
150.00 |
171.00 |
8.30 |
187.00 |
240.00 |
22.00 |
89.00 |
1830+/-5 |
|
225 |
225.00 |
261.00 |
9.40 |
277.00 |
340.00 |
27.00 |
102.00 |
1830+/-5 |
