     3V Gas Cooker Control board with Solenoid Valve 2TBL2-R

    3V Gas Cooker Controller with Solenoid Valve Function description

    The two poles can ignite separately or simultaneously. If they ignite simutaneously, they will ignite alternately every 1S.

    If the flame is out in ignition time, it can ignite again.

     It is with alarm function.

    The working signal synchronizes with valve holding signal.

    Main technical parameter

    Test item

    Standard

    Note

    Rated operating voltage

    3V



    Operating voltage range

    2-3.3VDC



    Ignition frequency

    8-15Hz

    3V

    ≥4Hz

    2.1V

    Ignition distance

    ≥5mm



    Ignition current

    ≤120mA



    Valve open current

    ≥450mA



    Valve  holding voltage

    ≥2.8V



    Ignition time

    8±1s

    3V

    Igniiton No.

    1 time



    Valve keep open time after ignition

    0.2±0.1s



    Valve open time

    0.5±0.1s



    Flame detection sensibility

    1N4007+15M



    Ignition energy

    ≥1mJ



    Ignition cycle

    ≤400ms



    Output hi-voltage

    ≥12KV

    with 30pF loading

    Ignition pulse width

    ≥12us



    Operating current

    ≤150mA



    Operating ambient humdity

    ＜95%



    Operating ambient temperature

    -10～70℃



    Storage temperature

    -20～75℃



    Life cycle

    ABS antiflaming>100,000 cycles
