316 Stainless Steel Plates

Stainless steel sheet Introduction

316L stainless steel plate is based on the test results: 316L stainless steel due to the addition of Mo, corrosion resistance, in particular, excellent pitting resistance; high-temperature strength is also very good; excellent work hardening (weak magnetic after processing); solid solution state no magnetic. 316L stainless steel grade: 00Cr17Ni14Mo2 The new national standard grade is: 022Cr17Ni12Mo2.

316L stainless steel chemical composition: C≤0.03 Si≤1.00 Mn≤2.00 P≤0.035 S≤0.03 Ni: 10.0-14.0 Cr: 16.0-18.0 Mo: 2.0-3.0

316 Stainless Steel Plates parameters

1.Outline: Add Mo (2~3%), excellent resistance to pitting, excellent high temperature creep strength.

2. Features of stainless steel plate

1) The glass of appearance of cold-rolled products is good and beautiful;

2) Due to the addition of Mo, corrosion resistance, especially excellent resistance to pitting corrosion;

3) Excellent high-temperature strength; transferred from "I want stainless steel"

4) Excellent work-hardening (weak magnetic after processing)

5) Non-magnetic in solution;

6) Relative to 304 stainless steel, the price is higher.

3. the scope of application: pipelines, heat exchangers, food industry, chemical industry.

4.chemical composition%:

1) C ≤ 0.03

2) Si≤1.00

3) Mn≤2.00

4) P≤0.035

5) S ≤ 0.03

6) Ni: 10.0-14.0

7) Cr: 16.0-18.0

8) Mo:2.0-3.0

5. heat treatment: Melting point: 1375~1450°C; Solution treatment: 1010~1150°C.

6. the use of state: Annealing solution states: NO.1, 2B, N0.4, HL, and other surface states.

Detect metals Steel Plates mechanical properties

1. Tensile strength (Mpa) 620 MIN
2. Yield Strength (Mpa) 310 MIN
3. Elongation (%) 30 MIN
4. Area Reduction (%) 40 MIN
5. The density of 316L stainless steel plate: 8.03 g/cm3, austenite stainless steel generally use this value
6. 316L chromium content (%) 16--18.<br/

Below are the details of our stainless steel sheet metal:

visit our website: https://www.angussteel.com/stainless-steel-sheet/stainless-steel-plates.html

Characteristics of 316 Stainless Steel Plates

Due to the addition of Mo, its corrosion resistance, atmospheric corrosion resistance, and high-temperature strength are particularly good. It can be used under harsh conditions; excellent work hardening (non-magnetic); excellent high-temperature strength; Cold-rolled products have good gloss and beautiful appearance; relative to 304L stainless steel, the price is higher.

Usage of Stainless Steel Plate

Equipment for production of seawater, equipment for the production of chemicals, dyes, paper, oxalic acid, fertilizers, etc.; photography, food industry, facilities in coastal areas, ropes, CD rods, bolts, nuts.
