Feature:  The sensors can accurately detect colors by light source, be able to detect subtle color difference.

Used application :  Vertical packaging machine, horizontal packaging machine, bag making machine, slitting machine, printing machine.

Specifications

1.         Item:       Standard

2.         Operating Voltage: 12-30 VDC

3.         Sensing Distance:   8mm or 12mm ± 10%,Selectable

4.         Current Consumption:   ≦ 40mA

5.         Power on Reset Time:    20ms

6.         Response Time:      0.25mS for KH Series

7.         1mS for KS Series

8.         Circuit Protection:  Output short circuit.

9.         Reverse polarity of supply voltage.

10.     Max. Load Current:        120mA

11.     Sealing:   Conforming to IP65 (IEC).

12.     Cable Length: 2 meter.

13.     Extraneous Light: Sunlight     100,000 LUX.

14.     Extraneous Light: Lamplight  10,000 LUX.

15.     Output Indicator:   Two output terminals selectable for Light-on and Dark-on.

16.     Light Source:   Red LED, Blue LED, White LED, Green LED
