    Product details

     LFP230Ah Standard Module     Vda Lithium Ion Battery Manufacturer      Vda Module



    LFP230Ah Lithium Ion Battery Standard Module is composed of 1P8S LFP54173204-230Ah, data collecting unit of BMS and fixed fittings. The capacity and voltage of LFP230Ah Standard Module is 25.6V230Ah. Standard module as the standard group structure can be connected in series to expand voltage and in parallel to expand capacity.



    Product Parameter Table

    No.

    Items

    STANDARD MODULE

    Note

    LFP230Ah 1P8S-25.6V230Ah

    1

    Nominal voltage(V)

    25.6



    2

    Operating voltage(V)

    min

    20

    T: 25±3℃

    3

    max

    29.2

    　T: 25±3℃

    4

    Nominal capacity(Ah)

    230

    1/3C，100%DOD

    5

    Nominal energy（KWh ）

    5.888

    1/3C，100%DOD

    7

    Group mode

    1P8S



    8

    Module weight（kg）

    35



    9

    Maximum continuous charge current（A）

    230



    10

    Maximum continuous discharge current（A）

    230



    11

    Maximum pulse charge current（A）

    460

    @10S，SOC≤70%

    12

    Maximum pulse discharge current（A）

    460

    @10S，SOC≥30%　

    14

    SOC operating range（%）

    10~90



    15

    Module cooling method

    Natural cooling



    16

    Module heating method

    No

    Or  heating film

    17

    Temperature detector qty.

    2



    18

    Shipping capacity (SOC)

    50%±5

    SOC is consistency in the same batch

    19

    Temp. Condition（℃）

    Charge

    0~55



    Discharge

    -20~55



    Storage

    -30~55



    20

    Dimension L （mm）

    480.9



    21

    Dimension W（mm）
