$6,499.00

INTRODUCTION:
Applying the technology of IPL and Bi-polar Radio Frequency, the system acts on the entire corium layer, epidermal layer and subcutaneous tissue. On one hand, IPL destroys pathological pigments by photothermolysis effect, and stimulates the collagen and elastic fiber and gets the effect of tightening and whitening, on the other hand, bio-polar RF release about 5 MHZ radio wave, high frequency vibration makes the skin molecule creating heat energy by friction, when the temperature reaches 68°C-72°C, the collagens extend will reproduce and recombine, enhance getting the effect of tightening skin and removing wrinkles.

Adopting the Q-Switched ND: YAG model, the equipment uses YAG to emit high energy instantaneously which smashing the pigment of pathological tissues, namely the YAG leading explosive effect: High energy emits instantaneously, making particular wavelength YAG penetrating epidermis and getting into pathological pigment tissues in only 6nms. Then pigments expand in top speed and explode. The superficial epidermis would be bounded out of body, other part of the pigments would split into granules which would be engulfed by macrophages, then exclude by the lymphatic system finally. The pigment becomes shallow gradually finally disappear while the surrounding normal skin tissues keep sound as they do not absorb particular wavelength YAG .

APPLICATION RANGES:
IPL&RF:
1) Wrinkle removal: Removing true wrinkle, pseudo-wrinkle, face lift-up.
2) Whole body rejuvenation .
3) Removing freckle, Chloasma, age pigment, sunburn, chorioplaque, etc.
4) Pigments removal: red face, and red capillary, acne , bottle nose etc.
5) Hair Removal: armpit hair, hairline, beard, whiskers, lip hair, body hair, bikini hair or any other unwanted hair.

Yag :
1) Pigment skin pathological changes, pigmentation caused by color pigment mixture, corium spot, freckle, mole, birthmark, nevus of Ota etc. 2)Specialized in removing red Capillary, coffee, brown and other colorized tattoos. (Tattoo removal)3)Effectively remove all kinds of embroider eyebrow, soak lip, eye line, and lip line.
TECHNICAL ADVANTAGE:
1. Applying all the advantages of IPL&RF and Yag technique, make the operation effect more conspicuous.
2. Modularized assembling, strong stability, Short operation period with outstanding effect.
3. Fully intelligent detecting system, avoid device damage caused by improper handling,Remove pigmentation without side effects .
4. 8″ TFT True Color Screen, functionalized designing menu, visual and easy handling.
5.Bran-new cooling system, super water cooling supplying for long time continuous working.
6. Artful lines designing, manual mechanic accordant operation handle, make the system Hi-tech and fashionable.

TECHNICAL PARAMETER
Ulse number:1~5pcs Single-pulse
Time of pulse:1.0~9.9ms Adjustable
Delay:1~150ms Adjustable
Spot Size:10*40mm

IPL Energy: 5-50J/CM2
Wavelength:1064nm~532nm
IPL Power: 1200W

Yag energy density:600~1500J/cm2
Yag Frequency:1~5Hz adjustable
Yag power:500W
RF Power:3~10MHz
RF Time:50~2500ms Adjustable
RF delay:0~10s Adjustable

Input Voltage: 110V±10% 50Hz-60Hz;220V±10% 50Hz-60Hz

FILTERS
430nm for Acne
480nm for age spots, sun spots, pigmentation troubles
530nm for wrinkle operation , Remove freckles.
560nm for Skin rejuvenation;
640nm for hair removal;
