1. Customize max 23 parameters
2. 2 patents obtained (Design patent and Utility model patent )
3. CE certificate
4. Bluetooth function of wireless outputting & printing
5. Mobile app compatible, convenient to be used in the small space
6. Online Software upgrade
7. Extended memory of 8G
8. ARM processor to offer higher speed, low power consumption.
9. 4 kinds of stylus ( probes) optional for the various work pieces
Main Technical Specifications
|
16 Parameters |
Ra, Rq, Rz, Rv, Rp, Rm, Rt, RS, Rsm, R3z, R3y, Rz(JIS), Rku, Rsk, Rmax, Rpc |
|
|
Display |
Ra、Rq：0.005-16μm；Rz、Ry、Rt、Rp、Rv、Rmax、R3z：0.02-160μm；RS、RSm：1mm；Rmr：0-100%（%Rt）；Rsk：0-100% |
|
|
Measuring Range |
±20μm、±40μm、±80μm |
|
|
Resolution (Ra) |
0.001μm |
|
|
Filter |
RC、PC-RC、GAUSS、D-P |
|
|
Cut Off |
0.25mm,0.8mm,2.5mm |
|
|
Probe |
Type |
Inductive |
|
Range |
160μm |
|
|
Stylus Radius |
5μm |
|
|
Measure Force |
4mN (0.4gf) |
|
|
Stylus Material |
Diamond |
|
|
Stylus Angle |
90° |
|
|
Number of cut-offs |
1 to 5 |
|
|
Max Running Length |
17.5mm/0.7inch |
|
|
Min Running Length |
1.3mm/0.052inch |
|
|
Accuracy |
≤±10% |
|
|
Traverse Speed |
0.5mm / s, 1mm/s |
|
|
Output |
USB and bluetooth |
|
|
Power |
Built-in rechargeable Battery |
|
|
Dimensions in mm |
140×52×48 |
|
|
Weight |
440g |
|
