Specification:
Thrust：250 kg/551 lb
Weight：8.5 kg/18.74 lb
Motor：8w
Mounting Flange（ISO 5210）：F07

Max. Stroke：50 mm/1.97 inch

Enclosure :
IP67、NEMA 4X：Water-proof and dust-proof enclosure.
Material：Dry powder coating aluminum alloy.
Position Indicator :
All models are equipped with continuous mechanical position indicator. The external stem visual position indicator provides easily read and instantly available stem position.
Modulating Controller :
Actuator can be operated according to input signal and provide the output signal for feedback.
Input signal：4~20mA, 1~5V or 2~10V.
Output signal：4~20mA or 2~10V.
Adjustable Stroke :
Allow users to adjust actuator’s stroke to match valve stem’s stroke. (Refer to the specifications for stroke range)
Motor :
All models are equipped with DC motor and provide low power consumption, high duty cycle and efficiency.(1500 starts per hour)
Working Conditions :
Ambient temperature：-30℃ ~ +65℃ / -22℉ ~ +149℉
The humidity：30％ ~ 95％
Over-thrust Protection :
If the output thrust of the drive exceeds of the drive rating, the actuator will shut off by two-step control. The two-step control is as follows:
First step : If the output thrust of the drive exceeds the rating, power supply will be turned off by limit switches.
Second step : If the limit switches fail, power supply will be turned off by electronic detector. (The function only applies to modulating controller actuator)
Slow-speed operation :
Besides the standard operating speed, if slower operating speed is needed, please contact with our sales person.
Conduit entrance :
standard : 1/2” NPT
option : M20,3/4” NPT
Various voltage :
24V AC/DC
110/220V AC
