OPERATION FEATURES:

●  The encoder of zero position, operation expediently
●  LCD panel is equipped on the controller for easy and interactive operation
●  Speed can be adjusted in 5 stages easily by controlling the operation panel
●  Invert system increases stability of controlling speed
●  Automatic stop and automatic test function
●  Automatic central lubrication

MECHANICAL FEATURES:

●  Automatic needle up and down changer
●  New take-down equipment brings high speed and Iow noise
●  Arbitrarily choose one from 2 feeders and 1 feeder can increase productivity and knit various patterns
●  New type of bearing increases running stability of needle cylinder

PATTERN DESIGN AND CONTROL SYSTEM:

●  For WINDOWS pattern design brings easy operation
●  Use serial feeding, avoiding program error and missing
●  12 steps electronic actuators

TECHNICAL FEATURES:

Cylinder diameters: 3.75” 4” 4.5”
Needle count: 96N-220N
Running speed: Max 300 RPM
Power required: 1 HP (0.75kw)

DIMENSIONS AND WEIGHT:

Floor space (WxLxH): 1000X1000X2200mm
Net weight: 400kg
Gross weight: 450kg
